Gas | Inlet connection | Outlet connection | Hp safety | Working pressure |
O2 | A | ISO | N | 200 |
Pin Index cylinder valve for medical gases - M966
High pressure chrome plated brass cylinder valve with yoke outlet connection for oxygen and medical gases.
Key advantages
- Low operating torque
- MRI compatible
- Key-operated or handwheel operating system
- Safe, long, trouble-free life under all service conditions
- Testing according to EN ISO 10297 and CGA U9 standards
Specifications
| Seat orifice size | 2.5 mm |
| Magnetic compatibility | yes |
| Key – operated | chrome plated |
| Handwheel material | plastic switch blade |
| Seat material | PA 6.6 |
| O-ring material | EPDM |
| Body material | Chrome plated brass |
| Filter material | brass sintered |
| Working pressure | 200 bar (2900 psi) |
| Temperature range | -25°C to +70°C (-13°F to 158 °F) |
| Helium leak rate at pmax | 10-3 mbar l/sec |
Dimensional drawings
